Complete Energy Storage System
20 kWh Solar Battery System for Home and Small Business Projects
Our 20 kWh solar battery system is a coordinated energy-storage package combining LiFePO4 battery storage with a selected inverter or power-conversion system and the required control and protection interfaces. It is intended for residential backup, solar self-consumption and smaller commercial sites where battery capacity and AC output power must be sized together.
Unlike purchasing a stand-alone battery, this system is specified as a complete electrical package. The inverter model, usable battery energy, operating mode, electrical accessories and any PV panels are defined in the approved project bill of materials.
Buyer Specifications
20 kWh System Specifications and Scope
Energy capacity is measured in kWh; inverter output is rated in kW. The final electrical ratings must match the selected system configuration.
| Specification | System Information | Purchase / Design Check |
|---|---|---|
| Product Type | Complete solar battery energy-storage system | Battery, power-conversion and protection scope listed in the BOM |
| Energy Capacity | 20 kWh-class storage system | Confirm exact nominal and usable energy in kWh |
| Battery Chemistry | Lithium iron phosphate (LiFePO4) | Cell/module manufacturer and battery configuration by model |
| Inverter / PCS | Included as part of the configured system scope | Exact manufacturer, model, rated AC kW, phase and surge capacity |
| Battery Voltage | Configuration-dependent DC battery bus | Rated voltage, operating range and inverter battery input |
| Battery Management | BMS coordination required | BMS functions, supported CAN/RS485 protocol and approved pairing |
| PV Interface | Depends on selected hybrid / off-grid inverter | MPPT count, PV voltage/current and array sizing |
| AC Output and Backup | Depends on inverter and system operating mode | AC voltage, frequency, transfer behavior and backed-up loads |
| Enclosure / Protection | Specified for each battery and inverter component | IP rating, earthing, breakers, disconnects and installation environment |
| Operating Limits | Component- and configuration-dependent | Charging temperatures, derating, usable DoD and current limits |
| Documents | System BOM and model-specific documents on request | Datasheets, wiring diagram, manuals and applicable test reports |
System Architecture
What Is Included in the Energy Storage System?
The quotation identifies the battery, power-conversion equipment, system interfaces and necessary electrical protection. The arrangement below shows the functional relationship, not a substitute for the approved wiring diagram.
LiFePO4 Battery + BMS
DC energy storage, battery protection and status communication
Matched Inverter / PCS
DC/AC power conversion and applicable charging control
Site AC Distribution
Selected backed-up loads, grid interface or off-grid circuits
Electrical Interfaces
Battery communication, DC protection, isolation, AC protection and system monitoring are specified according to the chosen equipment.
PV Array and Other Inputs
Solar modules, mounting, utility interconnection and generator input are defined separately if the project requires them. Their inclusion should be explicit in the BOM.
System Sizing
Select the Right 20 kWh Configuration
A 20 kWh energy target does not determine the inverter size or backup duration. Start with the site's loads and operating requirements.
List Essential Loads
Identify running kW, motor starting demand and which circuits must remain powered.
Define Backup Hours
Estimate the energy used by essential loads, including expected inverter losses and usable battery limits.
Check PV and Grid
Provide solar array details, AC phase, utility rules and charging-source priorities.
Approve the BOM
Confirm inverter model, battery configuration, protection, documentation and installation conditions.
Compatibility and Integration
Battery, Inverter and Site Interface Checks
| Interface | System Scope | What Must Be Matched |
|---|---|---|
| Battery ↔ Included Inverter / PCS | Core integration | DC voltage, charge/discharge current, BMS protocol and approved settings |
| Battery ↔ Monitoring | Configuration-specific | Required communication ports, alarms and access to operating data |
| Solar PV Array | Project option | MPPT range, string voltage, PV current, roof/ground installation and DC protection |
| Utility Grid | Site- and inverter-dependent | AC voltage/phase, export settings, grid-code approval and transfer behavior |
| Generator or Existing Inverter | Additional compatibility review | Input limits, synchronization, charging controls and manufacturer approval |
| Expansion / Parallel Operation | Only where supported | Battery module limits, firmware, cabling, protection and inverter capacity |
A compatible battery voltage alone does not establish BMS or inverter compatibility. The accepted pairing is identified by model and firmware where applicable.
Operating Conditions
Performance, Safety and Backup Design Limits
Usable Battery Energy
Nominal kWh and usable kWh differ. Backup estimates must account for permitted depth of discharge, temperatures and conversion losses.
Power and Surge Loads
The inverter's continuous kW and short-duration surge rating determine which appliances or motors can operate together.
Environmental Conditions
Use the selected equipment's charging temperature limits, ventilation, installation clearances and enclosure ratings.
Battery cycle life, warranty term, transfer time and efficiency are provided only against the approved model datasheet and its stated test conditions.
Project Applications
Applications for a Complete 20 kWh Solar Battery System
Home Backup Power
Size the system for selected essential circuits, outage duration and surge loads. Confirm whether backup operation is supported by the chosen inverter.
Residential PV Self-Consumption
Coordinate PV production, evening demand, tariff rules and battery charging settings to define the operating schedule.
Small Commercial Sites
Review the daily load profile, AC phase, duty cycle, protected circuits and local installation requirements before specifying equipment.
Documents and Project Supply
Technical Evidence and Ordering Information
We coordinate the system configuration and equipment supply for installers, distributors and project buyers. Exact part numbers and supporting documents are agreed for each order.
Technical Approval Documents
- Battery and inverter datasheets with matching model IDs
- System single-line / wiring diagram and BOM
- BMS compatibility information and operating instructions
- Applicable battery transport and safety reports
- Relevant market and installation documents, where available
Purchasing and Delivery Scope
- System quantity, inverter power and electrical configuration
- Battery modules, accessories and spare-part requirements
- Destination country, packaging and transport conditions
- Documentation, labeling and after-sales requirements
- Lead time, warranty and commercial terms in quotation
A test report or certification applies only to the models, holders and standard editions named on that document. Request the documents for the equipment actually quoted.
Alternative Purchase Scopes
Complete System or Battery Storage Hardware?
Choose the complete system when battery and power conversion need to be specified together. Buyers who already manage inverter selection may prefer a battery storage product.
20 kWh Battery Storage
Compare the battery-oriented purchase scope and request matching equipment details.
View Battery Product →Hybrid Solar Inverters
Review inverter families by AC output, battery voltage, PV input and local grid requirements.
Explore Inverter Options →Home Energy Storage Systems
Browse alternative system configurations and capacity options for residential storage projects.
Browse Energy Storage →Buyer Questions
20 kWh Solar Battery System FAQ
- Does 20 kWh mean the system has 20 kW output power? +
No. The 20 kWh figure describes energy storage. Continuous AC power is rated separately in kW and depends on the selected inverter or PCS.
- What comes with the complete 20 kWh battery system? +
The configured system covers LiFePO4 battery storage, a matched inverter or PCS, battery management interfaces and the necessary electrical protection. The exact modules, accessories and any solar panels are identified in the approved bill of materials.
- How long will the system supply power during an outage? +
Runtime depends on usable battery energy, the connected loads and conversion losses. Share the loads in watts or kilowatts and the required backup duration for a configuration review.
- Can it operate without a grid connection? +
Off-grid operation is possible only with an inverter and control arrangement designed for it. Solar charging, battery reserve and peak-load requirements must also be sized for the site.
- Are solar panels included in the system? +
PV panels are included only when specified in the project supply scope. The quotation separates the battery-and-inverter system from optional PV modules, mounting and associated installation equipment.
- Can the battery work with any hybrid inverter? +
No. Voltage, current limits, BMS communications and firmware need to match. Use the approved inverter model and pairing details supplied for the quoted system.
- Which certificates and test reports can be supplied? +
Document availability depends on the specific battery, inverter and destination market. Request current model-specific safety, transportation and conformity documents with the system quotation.
- What information is needed for a system quotation? +
Provide the destination country, AC phase and voltage, essential loads and starting power, daily energy use, backup hours, solar array details, operating mode, quantity and any local approvals required.
Project Quotation
Request a Complete 20 kWh Solar Battery System Quote
Send the electrical and application information below. We can then review the battery configuration, inverter/PCS selection, system protection and documents required for your market.
- Destination country and grid phase / voltage
- Continuous AC load (kW) and motor starting demand
- Required backup duration and daily energy (kWh)
- PV system size, if included in the supply scope
- Grid-tied, hybrid or off-grid operating mode
- Project quantity, delivery and document requirements
