Product Introduction
The Double Glass Module is an innovative solar energy product that exemplifies advanced technology and sustainability in the renewable energy sector. This state-of-the-art device is meticulously engineered to optimize energy output while ensuring exceptional durability and extended lifespan.
This unique photovoltaic module distinguishes itself through its unconventional construction, incorporating two layers of tempered glass as opposed to the traditional single layer design. This distinctive configuration not only furnishes augmented protection for the embedded photovoltaic cells but also facilitates bi-facial energy capture, allowing the module to harness sunlight from both sides. Consequently, it leads to a substantial increase in energy yield, particularly in environments abundant with reflected or scattered light.
Empowered by half-cut cell technology, the Double Glass Module demonstrates enhanced operational performance and robustness. The implementation of half-cut cells mitigates power loss due to shading effects, thereby boosting the module's overall efficiency. Moreover, this innovative design strategy diminishes the likelihood of hot spots, ensuring an extended service life and sustained high energy production over time.
| Solar Cells | Monocrystalline |
| No. of cells | 144 cells |
| Module Dimensions | 1762x1134x30 mm(69.06x43.15x1.18inches) |
| Weight | 21.0kg(46.30lb) |
| Glass | 1.6 mm (0.06 inches), High Transmission. AR Coated Heat Strengthened Glass |
| Encapsulant material | EVA/POE |
| Frame | 30mm (0.06 inches) Anodized Aluminium Alloy |
| J-Box | IP 68 rated |
| Cables | Photovoltaic Technology Cable 4.0mm2(0.006 inches2), Portrait: 350/280 mm(13.78/11.02 inches) Length can be customized |
| Connector | MC4 EVO2/EVO2A/TS4 PIus /TS4* |
Product Parameters
Key Features
Increased Energy Production with Bifacial Technology
When placed in reflecting surroundings or at the ideal tilt angle, the Double Glass Module maximises energy generation by capturing sunlight from both the front and rear. Its distinct bifacial characteristic optimises the generation of solar power.
Exceptional Durability and Reliability
A long operational life is guaranteed by the dual-glass construction's resistance to environmental influences. By reducing installation damage, the Vertex S glass improves structural integrity.
Ideal Performance in Tough Conditions
Built for robustness, the module excels in demanding settings including warm weather, high humidity, and coastal regions. It is perfect for challenging installations because of its excellent resistance to corrosion, rain, and fire, as well as its low temperature coefficient, which guarantees consistent operation.
Product Certificates
Powersourcing Warehouse
Products packaging
Production process
FAQ
|
Q: Can you tailor solar solutions to meet certain requirements?
A: Yes, we have the ability to offer solutions to solar energy users worldwide, as seen by our numerous successful examples and experiences. Q: How can I obtain an estimate? Please submit the following information so that we can deliver the best quote along with a thorough solution: 1.Rooftop area with no shadows 2. The highest load on a household 3. Monthly electricity bills 4. Power standards, such as wire systems, phase, voltage, and frequency 5. The intended placement of the cabinet and inverter 6. The quote will be sent out within 24 hours of the aforementioned data being received Q: How can I acquire your products' technical support? Our incredibly hardworking technical support staff is here to help whenever you need them. You can contact us by phone, email, or through any social media platform, and we will respond to any technical questions or issues you may have in a timely and courteous manner. After a contract is signed, we can provide local support for the second step. Q: What products do you offer? Solar panels, solar inverters, solar power systems, solar mounting, solar cables, and other solar accessories are among the things we can provide our customers. |
